Sh2-114 Flying Dragon Nebula

Emission nebula in constellation Cygnus.

Sh2-114 is a weak emission nebula in the constellation cygnus and has a slightly torn shape. The area obviously consists of several arcuate filaments lying on top of each other.

Please click on the image for a bigger view.
Object: Sh2-114
Date of exposures: 03.09.2018, 04.09.2018, 05.09.2018, 15.09.2018, 16.09.2018
Exposures: Ha 5nm: 154 x 300", OIII 3nm: 59 x 300", RGB: 78 x 300", Sum: 24,3 hrs.
Telescope: 10'', F4 Newton
Focal length: 1000mm
Filter: Astrodon RGB E-Series, H-Alpha 5nm, OIII 3nm
Camera: ASI 1600 MMC Pro
Guiding: Off Axis Guider, Lodestar
Mount: EQ8

The arcs have a semicircular shape with a depression facing south. It is suspected that this, together with the nearby Sh2-113 cloud, is a bubble shape that looks like a supernova remnant. To date, however, no supernova has been recorded or described in this region.
At the upper edge of the image is Kronberger (Kn) 26 - a bipolar emission nebula. A detailed analysis of the morphology and kinematics indicates the possible presence of two pairs of bipolar wings that would make Kn 26 a new member in the four-pole PN class.

The image was taken in 5 nights with over 24 hours exposure time from Ha, OIII and RGB images. Here the whole field:
